Features
- 150 Watts/channel into 8 Ohms
- High-current class A/AB output stage
- Classic STASIS design
- Balanced and single-ended inputs
- Massive custom toroidal power transformer
- Easily drives low-impedance reactive loudspeaker loads
- Low-noise solid-state design
- All discrete components
- Accurate, detailed reproduction
- Minimal feedback
- No transistor glare
- Direct coupled input to output for tight, extended bass
- Premium components
- Isolated power reserves for voltage and current gain stages
- Gold-plated RCA jacks & XLR connectors
- Custom high current speaker output terminal posts
- Traditional Threshold rugged chassis construction
- High reliability
- Designed in the USA
Technical Specifications:
- Nominal Power Output: 150 W/ch@8 Ohms;
- 300 W/ch at 4 Ohms
- Bandwidth Response: flat @ DC to –3dB @100kHz
- Noise: no greater than –100dB referenced
- to rated output
- Distortion: less than 0.1% (@1kHz, rated output power @8 Ohms)
- Input Impedance: 50k Ohm (RCA),
- 600 Ohm (XLR)
- Finish: Natural Aluminum
- Dimensions and Weight
- 19″ W x 8.75″ H x 13.25″ D,
- 48.26 cm W x 22.3 cm H x 33.7 cm D
- Weight: 54 lb/25 kg
